Model No. |
D210 |
D250,D250V |
|
Distance between centers |
400mm |
550mm |
|
Swing over bed |
210mm |
250mm |
|
Swing over cross slide |
110mm |
145mm |
|
Width of bed |
135mm |
135mm |
|
Taper of spindle bore |
MT3 |
MT3 |
|
Spindle bore |
21mm |
21mm |
|
Range of spindle speeds |
125~2000rpm |
125~2000rpm |
|
Range of longitudinal feeds |
0.10-0.20mm/r |
0.10-0.20mm/r |
|
Range of inch threads |
10-44T.P.I |
10-44T.P.I |
|
Range of metric threads |
0.4-3mm |
0.4-3mm |
|
Top Slide travel |
50mm |
50mm |
|
Cross slide travel |
110mm |
110mm |
|
Tailstock quill travel |
70mm |
70mm |
|
Taper of tailstock quill |
MT2 |
MT2 |
|
Motor |
550W |
550W |
|
Packing size |
1050 x 560 x 570mm |
1100 x 570 x 570mm |
|
Net weight |
105kg |
115lb | |
|
STANDARD ACCESSORIES |
|
OPTIONAL ACCESSORIES | |
|
Splash guard |
1pc |
|
Chip tray |
1pc |
|
Toolbox&tools |
1set |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
| |
|
|
Four-jaw chuck |
1set |
|
Follow rest |
1pc |
|
Steady rest |
1pc |
|
Face plate |
1pc |
|
ER25 Collet chuck |
1set |
|
Collet holdler |
1set |
|
Turning tools |
1set |
|
Speed readout |
1pc |
|
Stand |
1set | |
|
- Most popular,widely useful hobby lathe.
- V-way bed is hardened and precision ground.
- Spindle is supported by precision tapered roller bearing.
- MT4 spindle hole gets greater capacity.
- High precision chuck.
- T-slotted cross slide.
- Power longitudinal feed allows threading.
- Adjustable gibs for slideways.
- Top design of gearbox gets large function.
- Provide to cut right and left hand threads.
- Tailstock may be offset for turning tapers.
- Equipped with high quality of aluminum pulleys.
- A reversing switch is included for added versatility.
- Tolerance test certificate, test flow chart included.
|
|
SPECIFICATION: |
|
Model No. |
|
|
Distance between centers |
550/750mm |
16/22 |
|
Swing over bed |
250mm |
10 |
|
Swing over cross slide |
150mm |
6 |
|
Width of bed |
135mm |
5-1/3 |
|
Taper of spindle bore |
MT4 |
MT4 |
|
Spindle bore |
26mm |
1 |
|
Number of spindle speeds |
6 |
6 |
|
Range of spindle speeds |
125~2000rpm |
125~2000rpm |
|
Range of longitudinal feeds |
0.07-0.20mm/r |
0.003-0.008mm/r |
|
Range of inch threads |
8-56T.P.I |
8-56T.P.I |
|
Range of metric threads |
0.4-3.5mm |
0.016-0.137 |
|
Top Slide travel |
50mm |
2 |
|
Cross slide travel |
115mm |
4-1/2 |
|
Tailstock quill travel |
70mm |
2-7/8 |
|
Taper of tailstock quill |
MT2 |
MT2 |
|
Motor |
550W |
3/4HP |
|
Packing size |
1250 x 1450 x 570/770mm |
49 x 57 x 22/30 |
|
Net weight |
120/140kg |
264/308lb | |
|
STANDARD ACCESSORIES |
|
OPTIONAL ACCESSORIES | |
|
Splash guard |
1pc |
|
Chip tray |
1pc |
|
Toolbox&tools |
1set |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
| |
|
|
Four-jaw chuck |
1set |
|
Follow rest |
1pc |
|
Steady rest |
1pc |
|
Face plate |
1pc |
|
ER25 Collet chuck |
1set |
|
Collet holdler |
1set |
|
Turning tools |
1set |
|
Speed readout |
1pc |
|
Stand |
1set | |
|
